1. Flow scoring direction

Flow meters are directional, and most flow meters have directional requirements when installed, so the installation direction cannot be changed arbitrarily. Specifically, the direction can be determined by the markings: Most flowmeter casings have clear directional markings, with the most common being arrow markings indicating the positive direction in which the fluid should flow. For example, for some common flow meters, with this simple identification, installers can quickly determine the correct installation direction. Some orifice flow meters also use a plus sign to indicate direction, with the plus sign end facing the direction of the water flow. If installed in reverse, the error can reach 40%. It is best to install it at the lowest point of the pipeline for liquid measurement. Determine direction based on principle: In principle, the positive direction always corresponds to the high-pressure side. When installing the flow meter, the arrow should be consistent with the actual fluid direction, otherwise the measured data will be incorrect. This is because the design of the flowmeter is based on specific fluid dynamics principles, and only in the correct direction can the flow rate and other parameters of the fluid be accurately measured. If the direction is reversed, the direction of the force exerted by the fluid on the internal components of the flowmeter will change, leading to abnormal measurement signals and inaccurate measurement results. Direction requirements for special flow meters: Different types of special flow meters have their own unique direction requirements. When installing a turbine flowmeter vertically, the fluid must flow from bottom to top, with the arrow poi

nting upwards; The arrow marked on the vortex flowmeter is crucial. If installed upside down, it will strike directly. However, when measuring gases, the direction can be flexible, and when measuring liquids, it must be from bottom to top; The rotor flowmeter must be installed straight and vertically, and if it deviates by more than 5 degrees, an error will occur; Although the mass flow meter can be adjusted by setting the direction, it is best to install it according to the arrow. Different types of flow meters have different directional requirements: electromagnetic flow meters can be installed horizontally or vertically, but when installed vertically, if the water flow direction is reversed, bubbles will block the sensor, resulting in inaccurate measurement; In addition to the plus sign direction mentioned earlier, orifice flow meters also have safety requirements for installation positions during liquid measurement. It is best to install them at the lowest point of the pipeline to ensure measurement accuracy.

2. What is the result of installing the rotor of the rotor flowmeter upside down?

If the rotor of the rotor flowmeter is installed upside down, it will completely fail to work properly, not only causing inaccurate measurements, but also directly damaging the instrument.

. Yu Jiao1. Core Impact: Measurement Function Failure The working principle of the rotor flowmeter relies on the fluid flowing from bottom to top, and this thrust causes the rotor to steadily rise and suspend in the conical tube. The position of the rotor directly corresponds to the flow rate value. Once reversed, the direction of the fluids force will change vertically and horizontally, and the rotor will either remain stationa
