1. What is the measurement method used for E+H-91WA1 ultrasonic flowmeter?

Ultrasonic flowmeter mainly uses the time difference method for measurement, which is a common ultrasonic flow measurement material preparation technology. In the time difference method, the time difference of ultrasonic signals propagating in the fluid is used to calculate the flow velocity. Specifically, ultrasonic transmitters and receivers are usually installed on both sides of the pipeline, with signals transmitted from one side to the other while returning in reverse flow. By measuring the difference in propagation time between upstream and downstream, the average velocity of the fluid can be calculated. The advantage of this method is that it does not require direct contact with the fluid, reducing the need for maintenance and cleaning. However, there are also a few cases where Doppler effect is used for ultrasonic flow measurement. The Doppler method is mainly applied to fluids containing particles or bubbles, and calculates flow velocity by detecting the frequency changes of ultrasonic waves reflected back by particles or bubbles in the fluid. This method is particularly suitable for measuring wastewater or industrial waste liquids containing suspended particles in the cover mold, but it requires high fluid purity. Time difference method and Doppler method each have their own characteristics and are suitable for different application scenarios. The time difference method is suitable for most fluid environments, especially those that require high cleanliness, due to its non-contact measurement method. The Doppler rule is more suitable for complex fluids containing particles or bubbles, but may require regular calibration to ensu

re accuracy. It is worth noting that the 91WA1 ultrasonic flowmeter from E+H company adopts the time difference method, which enables it to work stably in various fluid environments and provide accurate flow data. This model of flowmeter is designed to be compact, easy to install, and suitable for various industrial applications such as water treatment, chemical production, etc. In summary, the time difference method, as the mainstream ultrasonic flow measurement technology, is widely used in industrial applications. Although the Doppler method has its unique advantages under specific conditions, the time difference method is more common in practical applications due to its versatility and accuracy.

2. What is the working principle of clamp type ultrasonic flowmeter? The working principle of clamp type ultrasonic flowmeter is mainly based on two techniques: time difference method and Doppler effect method, which calculate fluid velocity and flow rate through non-invasive measurement. Here are the specific principles and processes:
First, the principle of time difference method is based on measuring the flow velocity using the time difference between the forward and backward propagation of ultrasonic waves in the fluid.
. When the fluid in the pipeline is stationary, the propagation time of ultrasonic waves upstream and downstream is the same; When fluid flows, the propagation speed in the downstream direction increases (time shortens), while the propagation speed in the upstream direction slows down (time prolongs). Measurement process: Probe installation: Two ultrasonic probes are symmetrically installed outside the pipeline, one as the transmitter and the other as the receiver. Signal transmission: The
