1. Working principle and technical parameters of HKB gas flowmeter

Master the mystery of HKB gas flowmeter: precision induction and excellent performance. As a new generation of flow measurement tool, HKB series gas flowmeter, with its innovative technology of third-generation Xianbi capacitive force induction sensor, not only achieves significant improvement in dirt resistance and sensitivity, but also simplifies the installation process, maintenance free, and ensures the accuracy of measurement. Compared with the conventional differential pressure flowmeter, the HKB flowmeter cleverly solves the problem of easily clogged pressure tapping holes, making it an ideal choice for large pipelines, irregular pipelines, and even low-pressure and negative pressure environments. Excellent parameter reveals precise measurement. This gas flowmeter is designed for complex media such as coke oven gas, blast furnace gas, and generator gas. Its product parameters are as follows: Product name: Gas flowmeter, including blast furnace gas flowmeter and coke oven gas flowmeter. Applicable media: various types of gas, such as coke oven gas and blast furnace gas. Pipe diameter range: DN15 to DN3000mm and larger, supporting special specifications nominal pressure: 0.6-4MPa, flange connection working temperature: -20 ℃ to+450 ℃, special requirements can be customized. Measurement accuracy: ± 1.5% FS, ensuring high-precision reading signal output: 4-20mA, pulse frequency: 0-1000Hz, supporting RS485 communication protection level: IP65 and IP67, explosion-proof level Exiall CT4 or Exdll. CT4 display function: Accumulated traffic, instantaneous traffic, etc., facilitating real-time monitoring of working principles and revealing the powe

r of technology HKB The core of the series of intelligent gas flow meters lies in its capacitive force sensor. When the medium flows through the measuring tube, the pressure difference generated is converted into a force, and the sensor accurately captures and converts it into an electrical signal. This design not only has high precision, but also adapts to various harsh working conditions such as high viscosity, dirt, and extreme temperature environments. The highlight of the strong adaptability of the HKB flowmeter lies in its anti-interference and anti impurity performance, which not only provides the measurement advantages of conventional flowmeters, but also ensures stable measurement in complex environments. It has a wide adaptability to pipe diameters, can handle low flow rates and dirty media with ease, and is easy to install, greatly reducing maintenance costs. Installation instructions ensure optimal performance. During installation, professional guidance must be followed to avoid installing valves or elbows directly before and after the measuring pipe. Ensure the length of the straight pipe sections before and after to maintain the stability of the flow rate. After installation, it is necessary to perform a preliminary blow and ensure that the instrument housing is grounded. Overall, the HKB gas flowmeter provides an efficient and reliable solution for gas metering in industrial production with its precise technology, excellent performance, and flexible installation method, making it an ideal choice for improving production efficiency.

2. Formula for calculating coke oven gas production

Gas production (Nm3/h)=hourly coal loading (Zhengjue t/h) x (320-340) Nm3/t. This is only a calculated value v
