1. How to adjust the range of an electromagnetic flowmeter
The range adjustment of an electromagnetic flowmeter requires modifying the upper limit value of the range in the instrument parameters through device buttons or communication software. This operation will synchronously change the flow display range and output signal. 1. Range adjustment operation method: The range adjustment of electromagnetic flowmeter is mainly achieved through the following two methods: • On site button operation: enter the parameter setting menu through the instrument body button, find the "Range Upper Limit" or "Full Scale" parameter item, directly enter the new value and save it • Communication software setting: connect the configuration software through RS485/HART and other communication interfaces, modify the range parameters in the software interface and download them to the instrument. 2 When adjusting the range of key parameter settings, attention should be paid to the following parameter matching: • Range upper limit: usually set according to the maximum flow rate of the process, which is 1.2-1.5 times the normal flow rate • Range lower limit: generally kept unchanged at 0m ³/h (default cut-off point 0.5%) • Output signal: 4-20mA output will automatically follow the range change • Unit setting: needs to be consistent with the flow unit (m ³/h, L/min, etc.). 3 Operation precautions - confirm the sensor specification before modifying the range, which shall not exceed the rated range of the sensor - recheck the zero point after adjustment (usually adjust the range first and then adjust the zero point) - handle the work ticket and remove the interlock protection for instruments involving safety interlock - after parameter modi
_600x400.jpg)
2. AXF flowmeter user manual: [6]
AXF flowmeter user manual This manual mainly introduces the usage method and common fault solutions of AXF flowmeter.
1. Instructions for installation: Ensure that the installation position of the flowmeter meets the requirements and avoid strong electromagnetic interference and severe vibration.
. Connect the pipeline and flow meter correctly according to the instructions and steps in the manual, ensuring good sealing and preventing leakage. Startup and Calibration: Connect the power and follow the prompts on the operation interface to initialize the settings. According to actual needs, perform zero calibration and range calibration to ensure measurement accuracy. Daily operation: Real time monitoring of traffic data through the operation panel or remote control system. Adjust the parameter settings of the flowmeter as needed, such as measurement units, alarm thresholds, etc. Maintenance and upkeep: Regularly inspect the appearance and connecting components of the flowmeter to ensure no damage or looseness. C
