Principles of Sewage Flow Meter | Several Methods for Measuring Drainage Flow at Sewage Outlets

『Principle of sewage flowmeter』Related information(clamp on meter|electromagnetic meter|venturi meterrotameter|orifice meter|ultrasonic flow meter|mass flow meter|coriolis mass flow meter|coriolis flow meter|magnetic flow meter|magmeter flow meter|magflow flow meter|mag meter flow meter|electromagnetic flow meter|vortex flow meter|turbine flow meter|thermal mass flow meter|thermal flow meter|rotameter flow meter)

1. Sewage Doppler flowmeter

2. Instantaneous sewage flowmeter

The instantaneous sewage flowmeter can display the instantaneous flow rate and cumulative flow rate, measure the flow rate of sewage, and the sewage flowmeter Shanghai Menghui. The measurement principle of the sewage flowmeter is based on Faradays law of electromagnetic induction, which measures the volume flow of the conductive medium inside the induction measurement tube to calculate the flow volume. It adopts embedded technology of single-chip microcomputer to achieve digital excitation, and the bucket cover on the sewage flowmeter adopts CAN fieldbus, which is the first of its kind in China and the technology has reached the leading level in China. Sewage flow meters can not only meet on-site display requirements, but also output 4-20mA current signals for recording, regulation, and control purposes. They have been widely used in industrial technology and management departments such as chemical, environmental protection, metallurgy, medicine, papermaking, and water supply and drainage. In addition to measuring the flow rate of general conductive liquids, sewage flow meters can also measure the volumetric flow rate of liquid-solid two-phase flow, high viscosity liquid flow, and salt, strong acid, and strong alkali liquids. Sewage flowmeter Shanghai Menghui - Technical parameters 1: Instrument accuracy: Pipeline type 0.5 level, 1.0 level; Insertion type 2.5 level 2: Measurement medium: various liquid and liquid-solid two-phase fluids with conductivity greater than 5 μ S/cm. 3: Flow rate range: 0.2-8m/s4: working simulator pressure

1.6MPa5: ambient temperature: -40 ℃~+50 ℃ 6: medium temperature: PTFE lining ≤ 180 ℃ 7: rubber lining ≤

65 ℃ 8: explosion-proof mark: Exmibd Ⅱ BT49: explosion-proof certificate number: GYB0134910: external magnetic interference: ≤ 400A/m11: shell protection: integrated type: IP65; 12: Detached type: Sensor IP68 (5 meters underwater, limited to rubber lining) 13: Converter IP65 14: Output signal: 4-20mA. DC, load resistance: 0-750 Ω 15: Communication output: RS485 or CAN bus 16: Electrical connection: M20 × 1.5 internal thread, φ 10 cable hole 17: Power supply voltage: 90-220V. AC, 24 ± 10% V.DC18: Maximum power consumption: ≤ 10VA Sewage flowmeter - Performance features: 1. Simple and reliable instrument structure, no movable parts, long working life. 2: No flow blocking components, no pressure loss or fluid blockage. 3: No mechanical inertia, fast response, good stability, can be applied to automatic detection, adjustment, and program control systems. 4: The measurement accuracy is not affected by the type of measured medium and its physical parameters such as temperature, viscosity, density, pressure, etc. 5: Different combinations of PTFE or rubber lining materials and electrode materials such as Hc, Hb, 316L, Ti can adapt to the needs of different media. 6: There are various flow meter models available, including pipeline type and plug-in type. 7: Using EEPROM memory, the storage of measurement and operation data ensures safety and reliability. 8: It has two types: integrated and separated. 9: High definition Chu Du LCD backlit display.

3. Detailed explanation of the technical principle of Doppler ultrasonic flowmeter

The technical principle of Doppler ultrasonic flowmeter is mainly based on the Doppler effect and velocity area method to measure flow. By measuring the ultrasonic frequency shift and water
