1. How to determine the accuracy of the flow meter

2. How to repair the small display value of the eh mass flow meter

3. How to set up the thermal mass flow meter

The core settings of the thermal mass flow meter include parameter configuration, installation calibration, and communication settings, which must be strictly operated according to the instructions Basic parameter settings • Media properties: Enter the specific type of gas being tested (such as air, nitrogen), purity percentage, and working temperature and pressure range • Range: Set the minimum/maximum flow rate value based on the pipeline size and flow rate (e.g. commonly used 0-500 m ³/h for DN50 pipelines) • Unit selection: Switch display units (Nm ³/h, kg/h, SLPM, etc.) 2 Calibration Operation • Zero Calibration: Perform automatic zero adjustment in a no flow state (ensuring the valve is fully closed) • Span Calibration: Perform full-scale calibration using a standard flow source (such as a soap film flowmeter) • Temperature Compensation: Set the sensor temperature coefficient (usually 0.00385/℃ for platinum metal resistors) 3 Output signal configuration • Analog output: Set the flow range and response time corresponding to 4-20mA (usually adjustable from 0.5-30 seconds) • Pulse ou

tput: Set the pulse equivalent (e.g. 1 pulse=0.1m ³) and frequency upper limit • Alarm contacts: Configure high and low flow alarm thresholds and delayed triggering time 4 Communication Protocol Settings • HART Protocol: Set device address and communication rate (usually 1200bps) • PROFIBUS-PA: Configure DP address and diagnostic message type • Foundation Fieldbus: Set location number and function block link 5 Installation precautions • Ensure the requirements for the front and rear straight pipe sections (at least 10D in the front and 5D in the back) • Avoid installing in areas with strong vibration • Sensor probes must be fully inserted into the center area of the pipeline. Note: The new national standard GB/T 18940-2023 emphasizes that all calibrations must be performed under operating temperature and pressure conditions, and real-time temperature and pressure data should be input synchronously during setup. Dangerous operation prompt: Do not plug or unplug sensors under pressure. In explosion-proof situations, power must be turned off before operation.
