1. What are the measurement accuracy parameters of handheld ultrasonic flowmeter?

The technical parameters of handheld ultrasonic flowmeter measurement accuracy are better than 1.0%. Display 4 lines of Chinese characters on the same screen to display instantaneous flow rate, flow rate, cumulative flow rate, signal status signal output, non isolated RS232/1-channel isolated OCT output. Working temperature: ordinary type -20~70 degrees, high temperature type -20~160 degrees. The working power supply is built-in nickel hydrogen charging power supply, 220VAC installation method, external enclosure installation, DN15~Maxus DN6000 and Shunda flowmeter.

2. Measurement range of handheld ultrasonic flowmeter.

The technical parameters of FLEXIM handheld ultrasonic flowmeter F601/G601 are as follows: Measurement principle: Time difference related principle. Flow rate: 0.01~25 m/s resolution: 0.025 cm/s Repetitive Wodan Sock Performance: 0.15% reading, depending on application Accuracy: (Flow field fully developed and radially symmetrical) Volume Flow Rate: ± 1% reading, depending on application ± 0.5% reading, calibrated Flow Rate: ± 0.5% reading, depending on application Measurable Medium: All acoustic fluids, with a volume content of bubbles or solid particles<10% Host Shell Weight:~1.9kg Protection Level: IP65 (according to EN60529) Material: Aluminum alloy, Powder coating Size: (226 x 213 x 59) mm (WxHx D) Channel: 2 Hazardous Zone: Zone 2 Power Supply: Rechargeable battery (6V/4Ah); External power supply (100~240) VAC battery working time:>14h display: 2 x 16 characters, dot matrix, with backlight working temperature: -10~60 ℃ power consumption:<6W per mu signal average: (0~100) s, adjustable measureme

nt rate: (100~1000) Hz (1 channel) response time: 1s (1 channel), 70ms optional Measurement function Measurement quantity: volume/mass flow rate, flow rate, energy flow rate (temperature input required) Cumulative quantity: volume, mass, energy (optional) Calculation cavity excitation function: average, difference, sum Working languages: Czech, Danish, German, English, French, Dutch, Norwegian, Polish, Spanish Data recording Recordable parameters: all measurement quantities and cumulative quantity Capacity:>100000 measurement quantities Communication interface: RS232, RS485 (optional) Communicable parameters: measured values, recorded values, parameter recording software: FluxData (optional) Function: Download measurement values/records, graphic display, format conversion Operating system: ?? Windows TM ? Process output (optional) The number of output groups that are electrically isolated from the main device depends on the output type For more information, please contact FLEXIM. Current range: (0/4-20) mA Accuracy: 0.1% Reading ± 15 μ A Active output: Rext<500 ? Passive output: Uext<24V, Rext<1k ? Voltage range: (0~1) V or (0~10) V Accuracy: 0~1V: 0.1% Reading ± 1mV0-10V: 0.1% Reading ± 10mV Instrument impedance: Ri=500 ? Frequency range: 0~1kHz or 0~10kHz Collector open circuit: 24 V/4mA Switching quantity Collector open circuit: 24 V/4mA Dry spring relay: 48 V/0.1A Function, such as status output: upper and lower limits, symbol changes or errors Pulse output: Value: (0.01~1000) units Width: (80~1000) ms Process input (optional) Input is electrically isolated from the main device, with a maximum of 4 sets of inputs Temperature type: Pt100, four wire system range: -50 ℃~400 ℃ Resolution: 0.1 K Accuracy: ± (0.02K+0.1% re
