1. What are the symptoms of a broken car air flow meter?

The vehicle may experience shaking at idle, high fuel consumption, weak performance at high speeds, and black smoke from the exhaust pipe. The malfunction of an air flow meter can generally be divided into two situations: complete failure and abnormal signal. The former has no obvious external characteristics affecting the engine and is generally difficult for inexperienced people to detect. The latter will cause significant abnormalities in engine operation. Inaccurate signals from the air flow meter can cause errors in the ECUs fuel injection calculation, which can lead to various problems such as unstable idle, decreased power, and increased fuel consumption. The principle of air flow meter is that during the use of air flow meter, the gas flow passes through the flow meter to drive the turbine and potato blades to rotate. The number of revolutions of the impeller is directly proportional to the volume of gas passing through the air flow meter. There is a specially designed patented guide frame installed at the inlet of the flowmeter, which accelerates and bends the airflow entering the flowmeter as the flow velocity increases. The design of the guide frame can eliminate any potential fluid disturbances, such as eddies or asymmetric flows. The driving force on the turbine blades also increases simultaneously. Ensure high-precision measurement of the flowmeter within the allowable error range, even in low flow conditions. The airflow acting on the turbine blades is axial, and the turbine device is located on the main drive shaft, which is equipped with high-strength ball bearings. After the gas passes through the buried old turbine blades, the rotation

2. What is the function of a car air flow meter? What are the impacts once damaged? The core function of a car air flow meter is to measure the amount of air drawn into the engine and convert the signal into an electrical signal that is transmitted to the ECU as a key basis for controlling fuel injection, ensuring that the engine obtains the optimal air-fuel ratio mixture under different operating conditions. If it is damaged, the ECU will not be able to accurately obtain intake data, resulting in uncontrolled fuel injection, causing the mixture to be too rich or too lean, ultimately leading to abnormal engine operation, such as decreased power, unstable idle, weak acceleration, and even stalling. The specific function of an air flow meter is to accurately measure the intake volume: the engine requires different concentrations of mixture (air to fuel ratio) at different speeds and loads. The air flow meter monitors the air flow entering the engine in real time through physical or electronic means (such as hot wire, hot film, Karman vortex, etc.), ensuring that the ECU can adjust the fuel injection amount according to the intake air volume. For example, during rapid acceleration, as the intake volume increases, the air flow meter sends a signal to the ECU, which immediately increases the fuel injection volume to meet the power demand. As the core parameter for ECU control of fuel injection, the ECU calculates the optimal fuel injection quantity based on the signal from the air flow meter, combined with data such as engine speed, w
